| MOQ: | 1000M2 |
| Price: | Negotiation |
| Standard Packaging: | BOX /CARTON / PALLET |
| Delivery Period: | 10 Days |
| Payment Method: | TT / PAYPAL |
| Supply Capacity: | 600000 Square Meter/Square Meters per Month |
Polymer Type:
The core of the membrane is composed of a bituminous compound that has been modified with polypropylene (PP) polymer additives.
Reinforcement:
The membrane is reinforced with either a polyester mat or a fiberglass mat, or a combination of both, to provide enhanced dimensional stability, tensile strength, and tear resistance.
Surface Finish:
The surface of the membrane can be finished with various protective layers, such as mineral granules, metallic foil, or a polymer film (e.g., polyethylene, polypropylene). These surface treatments improve the membrane's resistance to weathering, UV exposure, and mechanical damage.
| Parameter | Description |
| Product Description | A multi-layered waterproofing membrane composed of a polymer-modified bituminous compound reinforced with a polyester or fiberglass carrier. |
| Composition | - Polymer-modified bitumen compound<br>- Polyester or fiberglass reinforcement mat<br>- Protective surface layers (e.g., mineral granules, metal foil, or polymer film) |
| Polymer Type | - SBS (Styrene-Butadiene-Styrene)<br>- APP (Atactic Polypropylene)<br>- SEBS (Styrene-Ethylene-Butylene-Styrene) |
| Reinforcement | - Polyester mat<br>- Fiberglass mat<br>- Combination of polyester and fiberglass |
| Surface Finish | - Mineral granules<br>- Metallic foil<br>- Polymer film (e.g., polyethylene, polypropylene) |
| Thickness | Typically ranging from 3 mm to 5 mm |
| Tensile Strength | ≥ 600 N/50 mm (ASTM D5147 or EN 12311-1) |
| Elongation at Break | ≥ 30% (ASTM D5147 or EN 12311-1) |
| Tear Resistance | ≥ 150 N (ASTM D5147 or EN 12310-1) |
| Water Tightness | ≥ 60 kPa (ASTM D5385 or EN 1928) |
| Resistance to Root Penetration | Passes (EN 13948) |
| Cold Flexibility | ≤ -15°C (ASTM D5147 or EN 1109) |
| Heat Resistance | ≥ 100°C (ASTM D5147 or EN 1110) |
| Applications | - Roofing systems (flat, sloped, green roofs)<br>- Below-grade waterproofing (basements, foundations)<br>- Plaza decks and podiums<br>- Water features and retention structures |
Video
Video
Video
Video
|
|
| MOQ: | 1000M2 |
| Price: | Negotiation |
| Standard Packaging: | BOX /CARTON / PALLET |
| Delivery Period: | 10 Days |
| Payment Method: | TT / PAYPAL |
| Supply Capacity: | 600000 Square Meter/Square Meters per Month |
Polymer Type:
The core of the membrane is composed of a bituminous compound that has been modified with polypropylene (PP) polymer additives.
Reinforcement:
The membrane is reinforced with either a polyester mat or a fiberglass mat, or a combination of both, to provide enhanced dimensional stability, tensile strength, and tear resistance.
Surface Finish:
The surface of the membrane can be finished with various protective layers, such as mineral granules, metallic foil, or a polymer film (e.g., polyethylene, polypropylene). These surface treatments improve the membrane's resistance to weathering, UV exposure, and mechanical damage.
| Parameter | Description |
| Product Description | A multi-layered waterproofing membrane composed of a polymer-modified bituminous compound reinforced with a polyester or fiberglass carrier. |
| Composition | - Polymer-modified bitumen compound<br>- Polyester or fiberglass reinforcement mat<br>- Protective surface layers (e.g., mineral granules, metal foil, or polymer film) |
| Polymer Type | - SBS (Styrene-Butadiene-Styrene)<br>- APP (Atactic Polypropylene)<br>- SEBS (Styrene-Ethylene-Butylene-Styrene) |
| Reinforcement | - Polyester mat<br>- Fiberglass mat<br>- Combination of polyester and fiberglass |
| Surface Finish | - Mineral granules<br>- Metallic foil<br>- Polymer film (e.g., polyethylene, polypropylene) |
| Thickness | Typically ranging from 3 mm to 5 mm |
| Tensile Strength | ≥ 600 N/50 mm (ASTM D5147 or EN 12311-1) |
| Elongation at Break | ≥ 30% (ASTM D5147 or EN 12311-1) |
| Tear Resistance | ≥ 150 N (ASTM D5147 or EN 12310-1) |
| Water Tightness | ≥ 60 kPa (ASTM D5385 or EN 1928) |
| Resistance to Root Penetration | Passes (EN 13948) |
| Cold Flexibility | ≤ -15°C (ASTM D5147 or EN 1109) |
| Heat Resistance | ≥ 100°C (ASTM D5147 or EN 1110) |
| Applications | - Roofing systems (flat, sloped, green roofs)<br>- Below-grade waterproofing (basements, foundations)<br>- Plaza decks and podiums<br>- Water features and retention structures |
